UCoustic Range Features- available in different sizes
- optionally available with real wood veneer
- spacious internal dimensions
- ships fully assembled
UCoustic Server Rack Cabinets - 9210 Active, 8210 Wall Box, 8250 Mini Cabinet and 7250 Wall Cabinet
Models: 9210 Active 12U, 24U, 42U (Optional Real Wood Veneer)
UCoustic 9210 Active is a premium range of quiet server rack cabinets which reduce equipment noise so that it is unnoticeable in a quiet office, whilst providing a thermal load capacity of up to 7.2 kW (equivalent to 37 single processor servers and peripherals). This range of cabinets is thermostatically controlled and the rear fan blowers move air through the server rack cabinet to keep it cool using minimum power consumption. In addition there is extra room for cable routing and an optional washable dust-filter to help protect the installed IT equipment.
You can upgrade your UCoustic Active cabinet with real wood veneer. Oak or Maple are the most popular real wood finishes but virtually any wood type is available (at additional cost). Upgrade a combination of front doors, top and sides to suit your requirements. Please note that the UCoustic Premium Wood is a fire enclosure (unlike some alternatives) unless the wood sides' option is taken.
Models: 8210 12U Wall Box & 8250 12U Mini Cabinet
The UCoustic 8210 wall mounted cabinet Box and 8250 compact mobile floor standing cabinet are great for locations short on space as they have a shorter depth of 700mm. They are particularly useful for reducing noise from switches and routers and audio-visual equipment, have a thermal load capacity of up to 4 kW and have an optional washable dust-filter.
Models: 7250 Wall Cabinet 12U, 18U, 21U
The UCoustic™ 7250 Acoustic wall mounted quiet rackmount cabinet comes in 12U, 18U and 21U sizes and is great for silencing noisy switches and routers - achieving up to 15dB(A) noise reduction performance. This range is available with optional top and bottom baffling chambers and has a thermal capacity of up to 1kW for the 2 fan models and up to 1.5kW for the 3 fan models.
For a competitive quote or to find out more about quiet racks please complete
the form on our
CONTACT page and we will arrange for our U.S. partner to get one of their authorized dealers
to contact you.
Click on a number to view more gallery images:
For a competitive quote or
to find out more about quiet racks please complete the form on our CONTACT page and we will arrange for our U.S. partner to get one of their authorized dealers
to contact you.
Technical Specifications - 9210 UCoustic Server Rack Cabinets
| Product Code | UC1-1292-AA |
UC1-2492-AA |
UC1-4292-AA |
| Product Code (with real wood veneer) | UC1-PWDT1292-AA |
UC1-PWDT2492-AA |
UC1-PWDT4292-AA |
| Useable Height | 12U |
24U |
42U |
| External Cabinet Dimensions in mm (Height/Width/Depth) (includes height of castors) |
28.2" x 30.71" x 47.63" |
49.21" x 30.71" x 47.63" |
80.71" x 30.71" x 47.63" |
| Max. Useable Depth* | 34.38" |
||
| Max. Rackmount Unit Depth | *33.86" (measured from front blanking plate surface to inside of rear door) |
||
| Assisted Cooling Mechanism | 2 x fan blowers located in rear doors |
||
| Cabinet Weight | 260.15 lbs |
394.63 lbs |
656.98 lbs |
| Cabinet Weight (with real wood veneer) | 246.92 lbs |
369.35 lbs |
579.82 lbs** |
| Max. Ditributed Load (total equipment weight) | 1102.31 lbs |
||
| Castors | Supplied as Standard |
||
| Cable Entry | Standard - located at bottom rear Multiple top/bottom locations are available Each cable entry is 3.94" x 12.2" |
||
| Cabinet Colour | Black with Montana Blue trim |
||
| Cabinet Features | Heavy Duty Steel Construction Removable side panels & doors for easy access Key lockable doors and side panels |
||
| Dust Ingress Protection | A Removable and washable filter is available as an optional accessory |
||
| Delivery | Delivered fully-assembled and ready to go |
||
Technical Specifications - UCoustic 8210 Wall Box & 8250 'Mini' Cab
8210 |
8250 |
|
| Product Code | UC3-1282-AA |
UC1-1282-AA |
| Useable Height | 12U |
12U |
| External Cabinet Dimensions in mm (Height/Width/Depth) | 24.41" x 30.71" x 27.56" |
28.19" x 30.71" x 29.72" (includes castors) |
| Max. Distance between front & rear mounting profiles | *14.96" This allows a 1.97" gap between rear mounting profiles and rear fan unit. |
|
| Max. Rackmount Unit Depth | 18.11" (Measured from front blanking plate surface to inside of rear door. This is reduced to 16.93" at the top of the cabinet, opposite the rear cooling fans.) |
|
| Assisted Cooling Mechanism | 3 x ultra-quiet rear fans |
|
| Assembled Weight without Rackmount Equipment | 160.6 lbs |
|
| Max. Distributed Load (total equipment weight) | 550 lbs |
|
| Castors | N/A |
Supplied as Standard |
| Cable Access Dimensions | Side cable access point x 2 : 1.57" x 5.71" |
|
| Cabinet Color | Black with Montana Blue trim |
|
| Cabinet Features | Heavy Duty Steel Construction Removable side panels & doors for easy access Key lockable doors and side panels |
|
| Dust Ingress Protection | A Removable and washable filter is available as an optional accessory |
|
| Delivery | Delivered fully-assembled and ready to go |
|
*The cabinets are assembled with a 1.72" recess from the front. The recess ensures sufficient space for the free-flow
of cool air to installed equipment.
**42U real wood does not require
top - doors and side panels only.
